• PatentedExposed Zero Lock n Stop elevation turret
• 30mm Mono-tube chassis
• Side Focus
• Illumination
• Wide Angle FOV
• High volume eyebox
• 100mm eye relief
• Multi-LED high intensity reticle
• High grade, low dispersion Crown glass
• 21 layer Fully Multi-Coated lenses
• Zoom magnification throw lever (removable)
• Fast focus eyebell with lock ring
• Supplied with Professional metal flip-up covers.

LR Dot Reticle

The LR Dot reticle was developed around a typical centrefire trajectory, like the .308 Winchester round, which is popular around the world for shooting fairly large game. It also suits some of the faster bullets that might be used for hunting foxes and similar quarry.

This design also makes it suitable for European shooters who might prefer a metric set of figures and therefore to zero their rifle in for 100 metres on the centre crosshair and use the lower aim points for 200, 300, 400 and 500 metres. A useful tip: at 16x magnification, the thick posts to the right and left of the centre dot would bracket the body length of a Roe deer at 100yds; a popular sized animal to hunt with this type of reticle.

Optical SystemSystem H7Scope Tube30mmMagnification5 – 30xObjective Lens56mmReticleLR Dot (16x)Illumination6 Levels with Off Positions In-between – RedParallaxSide FocusFocal PlaneSFP (Second Focal Plane)Lens CoatingFully Multi-Coated – 21 Layers
Field of View22.5 – 3.6ft @100yds7.5 – 1.2m @100mField of View ()4.3 – 0.7Eye Relief4in102mmPX/Focus15yds – 14m – Exit Pupil0.44 – 0.0711.2 – 1.9mm
Turret TypeZero Lock ‘n’ StopTurret CapsN/AClick Value14MOAElevation Turret Clicks (max)60 MOAWindage Turret Clicks (max)60 MOA
Ocular TypeLocking Fast FocusPower SelectorKnurled Posi-Grip with Removable Zoom Lever
Length15.8in401mmWeight25.5oz724g
