DC Output

Maximum DC output voltage

29.2V

Maximum DC output current

30A

Maximum DC output power

900W

Nominal DC output current

30A @ 110 VAC, 30A @ 220 VAC
22A @ 110 VAC

Battery type

Lithium

AC Input

AC input voltage range

85-270 VAC

Nominal AC input voltage

100-240 VAC

Nominal AC input frequency

50 / 60 Hz

Maximum AC input current

16A

Nominal AC input current

10A

Power factor

>0.9

Mechanical

Dimensions

28.2 x 12.4x7.2cm (11.1 x 6.57 x 4.5)

Weight

9.0 lbs 4.1 kg

Cooling

Active cooling with fan

Environmental

Enclosure

IP66

Humidity

5% 95%

Operating temperature

-40to +65(-40oF to 149oF)Derated at >40 (104)

Storage temperature

-40 to +85 (-40F to 185F)

LED

ChargerStatus

1. LED solid green.

1. The charger is ready to charge, or Charging is complete.

2. LED Green blinking.

2. The charger is charging.

3. Red light blinking quickly.

3. Input power failure.

4. LED Red and green blinking alternately.

4. The output is short-circuited or the positive and negative poles of the battery are reversed.

5. Red light blinks 2 times, interval 1 second, blinks 2 times again.

5. Charger temperature overheating alarm.

6. Red light blinks 3 times, interval 1 second, and then blinks 3 times.

6. Output overcurrent alarm.

7. Red light blinks 4 times, interval 1 second, then blinks 4 times.

7. Output over-voltage alarm.
